System Stead RAL 9006 RF 8,2 MHz

Radio Frequency (RF) 8.2 MHz Electronic Article Surveillance System

Technology:
Radio Frequency (RF) 8.2 MHz

Antenna design:
Coated steel tube: silver grey lacquer (RAL 9006)
Robust system with flexible tilting antennas

Features:
Perfect detection of all RF 8.2 MHz protecting elements
Suitable for all types of shops

Optional:
- built-in customer counter with Internet browsing in a program in Czech, English and Polish
- built-in detection of tinfoil, metal and magnets, discreetly warning shop staff of a pager or stroboscope
- possibility of remote service via Internet

Antenna dimensions and weight:
Antenna Dimensions: 1 612 x 405 x 45 mm
Base Dimensions: 300 x 68 mm
Antenna weight: 5 kg

Basic Configuration:
2-antenna (TX + RX), i.e. one transmitter antenna (TX) and one receiver antenna (RX); the detection field is between the antennae.

Expanded configuration:
For wider passages, the system can be expanded by alternately adding additional antennas, such as 3-antenna (RX + TX + RX) or 4-antenna (TX + RX + TX + RX), etc.

Kit contents (this system configuration):
1 pc transmitting antenna (TX)
1 pc receiving antenna (RX)
1 pc power supply unit 230VAC/24VDC 2,7 A (PSU)

Detection distances, passage width:
up to 160 cm for labels between antennas
up to 180 cm for hard tags between antennas
maximum detection distance in ideal undisturbed environment
